Access Control
Hikvision DS-K1102M Proximity RFID Reader
KES 4,500
Available- Official Hikvision stock
- 1-year manufacturer warranty
Key specifications
Frequency
125kHz
Read range
5 cm
Interface
Wiegand 26/34
Ingress protection
IP65
The Hikvision DS-K1102M is a 125kHz proximity RFID reader with a read range of up to 5cm, IP65 weatherproof rating, and Wiegand 26/34 interface. Ideal for access control applications in offices and commercial buildings.
Specifications
- Frequency
- 125kHz
- Read range
- 5 cm
- Interface
- Wiegand 26/34
- Ingress protection
- IP65
- Voltage
- 12V DC
- Current consumption
- 100mA
Key features
- 125kHz EMID proximity reader
- Read range up to 5cm
- IP65 weatherproof rating
- Wiegand 26/34 output
- LED and buzzer indicators
What's in the box
- •DS-K1102M reader
- •Mounting bracket
- •Screw kit
- •User manual
Optional extras
Frequently asked questions
What type of cards does this reader support?
It supports 125kHz EMID proximity cards and key fobs.
Can it be used outdoors?
Yes, it has an IP65 rating for outdoor installation.
What is the read range?
The read range is up to 5cm from the reader.
Is it compatible with third-party access controllers?
Yes, it outputs Wiegand 26/34, which is a standard interface for most access controllers.
Does it have visual and audio feedback?
Yes, it includes an LED indicator and buzzer for card read confirmation.
What colour options are available?
The DS-K1102M is available in black or white finishes.
